LP15 106 HHS (cable) 200mm LED 106x106cm folding frame + side slide

LP15 Warning Arrow — horizontal raise-and-lower with side slide · 105 × 105 cm Vehicle-mounted signalling panel for directing traffic around roadworks, incidents and lane closures. Approved per the applicable Danish Road Directorate regulation on roadworks marking. 15 amber Ø200 mm LED lamps (60 LEDs per lamp) in a matte-black aluminium housing with stainless-steel frame and IPX6 impact-resistant plastic lamp covers. Panel size 1050 × 1050 mm. Standard panel size for vehicles of all weight classes (under and over 3,500 kg). Horizontal electric folding frame (Linak actuator) for mounting on roof or roof-rack, with integrated side-slide frame for lateral positioning over the vehicle outline. CE / EN 12352 class L8H. 12 V (24 V via external converter kit). RS485 canbus control with back-lit operator panel and photosensor-driven 5-level automatic dimming per Vejdirektoratet requirements. Display modes: cross · arrow left · arrow right · corner lamps. Weight approx. 40 kg (including side-slide frame) — confirm on build sheet. Cable-connected remote control — select hand controller separately (2+4 or 3×5 layout).
